Dual Grade Site Display AGL GeoMax Gradoplane 25X

AGL Laser Systems
SKU: 6009254
The AGL GradoPlane 25X is used for site preparation, land leveling, trenching, road construction, pipe laying, and general construction.

Included items:
  • AGL GradoPlane 25X Laser Level
  • AGL LS100 Laser Detector
  • One Rechargeable Battery Pack
  • 4 Alkaline D-cell Batteries
  • Laser Carrying Case
  • Owner's Manual
  • Two-Year Manufacturer's Warranty
  • Description
    The new AGL GradoPlane 25X is a high performance dual grading laser for horizontal and up to 25% slope capability. Just align the GradoPlane 25X laser level to your pad and dial in your percentage (.001%). It features a new longer range, 3600' diameter, and optional remote capability that make it ideal for precise grading control for large construction sites or agricultural land leveling and farming. The GradoPlane 25X rotary slope grade laser level can also be used as pipe lasers for certain utility operations -- give Benchmark Bob a call or email for information.

    • Temperature corrected for long range accuracy.
    • Works great with the optional Apache Storm Laserometer detector for increased ease of use, range and accuracy.
  • Specifications
    Laser detector
    AGL LS100
    Accuracy
    ± 10 arc sec, ± 1/16" in 100' ( ± 1.5mm in 30m)
    Operating rage (diameter)
    3,600' (1,100m)
    Self leveling range
    ± 5° (manual mode for special applications)
    Grade capability
    -5 to +25% in either axis; -5 to +15% in both axes
    Laser beam type; rotation speed
    Visible 635nm, Class 2; 300 - 600 - 1,200rpm
    Battery life
    130 hrs with 8 D-cells, 100 hrs with optional 2 NiMH rechargeable battery packs
    Operating temperature
    -4° to 122° F (-20° - 50°C)
    Water and dust resistant
    IPX7 (waterproof)
    Size 10.4" x 10.2" x 8" (265 x 260 x 200mm); 11 lbs (5kg)
    Warranty
    2 year

    The AGL GradoPlane 25X has a unique power system that is very flexible and can provide weeks of operation. Supplied with one rechargeable battery pack and charger, 4 Alkaline D cells can be added if battery goes dead. Optional 2nd rechargeable battery pack can be added or run on 8 alkaline batteries. Optional sighting scope for alignment of laser to pad.
  • Downloads
    AGL GradoPlane 25X Brochure Coming Soon
Price:
$3,749.00
