GeoMax Zone20H Horizontal Laser Rotating, level Calibration included

AGL / GeoMax
SKU: 6010635
GeoMaz Zone20H Construction rotating Laser with basic detector Similar specs as Topcon RLH-5A ,
Without a doubt the best entry level laser available
red beam visible
3000' diameter range
3/32" accuracy at 100' feet
Has a visible beam for indoor use Supplied with ZRB35 basic receiver / detector,
Large 3 1/2" pickup area (largest in Class) on the detector / Receiver with rod Bracket With HD carrying case

Zone20 H is an economic and firm entry level laser rotator. With a solid-built housing and a straightforward interface, this laser offers all functions needed for regular and flexible use. Zone20 H is an automatic horizontal laser that allows grade setting manually in two axes. It is easy to use and highly reliable in any element. Tough and simple to use The Zone20 H complies with the IP67 class of water and dust protection due to its solid-built housing as well as the glass cage. The rubber molded handles and bumpers provide great protection and easy grip.

With only four buttons, as well as an informative LED-indication on the laser, the device is very simple and easy to use for everybody. Information regarding battery and tool status can be quickly obtained. Reliable operation,The Zone20 H is the ideal product for outside applications, such as concrete as well as formwork. As contractors need to constantly check the height of the concrete to ensure optimum levelling, Zone20 H solves this by allowing reliable operation. Thanks to the possibility to tilt the grades manually, contractors with occasional need for simple slopes like driveways and landscaping will get the most out of the Zone20H

Calibration included with all of our rotary laser levels.

  • Description

    GeoMax Zone20H Laser Rotator

    • The Zone20H is a laser tool for general construction and leveling applications such as setting forms, checking grades, and controlling depths for excavations
    • If set up within the self-leveling range, the Zone20H automatically levels to create an accurate horizontal plane of laser light.
    • Once the Zone20H has leveled, the head will start rotating and it is ready for use.
    • 30 seconds after the Zone20H has completed the leveling, the H.I. Alert system becomes active and protects the Zone20H against changes in elevation caused by movement of the tripod to ensure accurate work.
    • Horizontal manual slope matching in dual axis.
    • Economic and firm entry-level laser rotator. With a solid-built housing and a straightforward interface, this laser offers all functions needed for regular and flexible use.
    • Comes with a 3-year cover-all Geomax warranty.

  • Downloads
    GeoMax Zone20H Brochure Coming Soon.
