Pro Shot Alpha-v Vertical Plumb Highrise Laser Level

Laser Reference ProShot
SKU: 0020-0020-LV2
The Pro Shot Alpha-V is used for alignment plumbing through extended heights. This is particularly useful for the builder or surveyor when working with heights that are inaccessible or too large to plumb with string lines. The Pro Shot Alpha-V is also used for construction of vertical shafts and similar structures like massive vertical cable ducts or elevator paths.

The ProShot Laser levels from Laser Reference are precision instruments that provide speed, accuracy and durability on the job-site. Construction lasers that combine the most desirable features, durability, accuracy and at the best price in the market. Incorporated in 1991, Laser Reference has sold over 90,000 laser transmitters worldwide. Free UPS USA Shipping!
  • Beam diameter leaving laser 3/8".380 inch
  • Beam diameter at 100m (330') 7/16" .440 inch
  • Range to 100m, 330 feet
  • Height 6.5" weight 4.0 lbs
  • 24 mo. Warranty coverage
  • Out of Level indication, after self leveling, if the laser got bumped light will flash


Recommended alternative is the Laserline Quad 1000 Precision Zenith Plumb Laser.
or FOIT Laser/optical plummet
Check out video of laser dot at 12 stories https://www.youtube.com/watch?v=QdAElCNsYFE
  • Description
    The Pro Shot Alpha-v is used for vertical alignment plumbing through extended heights. This is particularly useful for the builder or surveyor when working with heights that are inaccessible or too large to plumb with string lines. The Pro Shot Alpha-v is also used for construction of vertical shafts and similar structures like massive vertical cable ducts or elevator paths.

    • Good for high rise construction, tunneling, towers or anywhere you need accurate precision vertical alignment.
    • 5 second plumb up accuracy 5" seconds is 1/16" @ 100'.
    • The Pro Shot Alpha-v offers the highest level of plumb up precision in its class: 5" seconds above and 1.5mm below.
    • Since laser beams are directed both up and down, it is easy to locate points vertically from a given point on the ground.
    • Application examples: tower work, high-rise work, elevator shaft, construction, vertical piping construction, vertical cable ducts, transfer of vertical survey points to ground, and ceiling work.

  • Specifications
    Measurement range up
    330' (100m)
    Measurement range down
    16' (5m)
    Beam accuracy up
    ± 5 arc sec
    Beam accuracy down
    ± 1 arc min
    Self-leveling range
    ± 4º, servo motor leveled
    Power supply
    Four C-cells (alkaline)
    Run time: down beam on
    65 hrs (continuous)
    Run time: down beam flashing 100 hrs (continuous)
    Automatic shut-off
    If off-level for more than 3 min
    Dust and water sealed
    To international standard IP56
    Operating temperature -4º F to +122º F (-20º C to +50º C)
    Storage temperature
    -40º F to +140º F (-40º C to +60º C)
    Laser classification
    CDRH Class 3A, IEC 825-1 Class 3R
    Height; weight
    6.5" (16.5cm); 4.0lbs (1.8kg)
