GeoMax Zone60 HG, Semi Automatic Duel Grade Laser Rotator

AGL / GeoMax
SKU: 6010659
GeoMax Zone60 HG Laser Rotator with Dual Slope SEE Feature tab for semi automatic feature
3000' diameter 8% grade

GeoMax products are built to withstand all environmental conditions. GeoMax equipment is built with the intention to withstand all conditions you run into during your daily work. Rain, hail, snow or intense heat will never affect your GeoMax equipment, you can always keep working to get the job done. GeoMax products are built to withstand all environmental conditions. GeoMax equipment is built with the intention to withstand all conditions you run into during your daily work. Rain, hail, snow or intense heat will never affect your GeoMax equipment, you can always keep working to get the job done. Adding easy-to-use, dial-in grade capability to the dependability of the Zone40 H core, this laser is more flexible in use and enables semi-automatic grade in levelling applications.
Range 3000' diameter
8% grade or slope
  • Description
    Features:

    GeoMax Zone60 HG Laser Rotator with semi automatic dual slope,
    Use as a single or dual slope grading laser 1/16" accuracy
    3000' diameter range, 8% slope / grade range

    • Adding easy-to-use, dial-in grade capability to the dependability of the Zone40 H core, this laser is more flexible in use and enables semi-automatic grade in levelling applications.(see Feature Tab)
    • Horizontal digital slope in dual axis (semi-automatic).
    • Adding easy-to-use, dialing grade capability to the dependability of the Zone40 H core, this laser is more flexible in use and enables semiautomatic grade in levelling applications.
    • NEW style Basic detector and case
    • Comes with 3-year full-cover warranty.


  • Features
    The Zone60 HG is a semi-automatic laser. Semi-automatic means that the laser self-levels only when in Level mode, not when grade is entered.
    Once the Zone60 HG has levelled, the head will start rotating and the Zone60 HG is ready for use. 30 seconds after the Zone60 HG has completed the levelling, the Elevation Alert (H.I.) function becomes active and protects the Zone60 HG against changes in elevation caused by movement of the tripod to ensure accurate work.

    In Grade mode the Zone60 HG checks first the position of the beam at level, and then adjusts to the desired grade input. If a single grade is entered, the cross axis will continue to self-level. Once the Zone60 HG has reached the desired grade, it does not self-level, but is monitored by Bump Alert and temperature change functions to ensure reliable grade values.

    The delivered components depend on the package ordered. Zone60 HG Laser Components Zone60 HG laser components Zone60 HG laser semi Automatic slope , ZRB35 Receiver, Alkaline, Carry Case
Price:
$1,254.00
