Pro Shot AS2 Magnum Slope Laser Level up to 25% with R9 Detector made in USA

Laser Reference ProShot
SKU: AS2 Magnum
The Pro Shot AS2 Magnum Slope has a 3,300 foot working diameter with handheld or machine-mounted receivers.
up to 25% single grade, Dual slope capable
Included items:
  • Pro Shot AS2 Magnum Laser Level
  • Pro Shot R9 Laser Receiver Detector
  • Rod Clamp
  • Four C-Cell Batteries
  • Laser Carrying Case
  • Owner's Manual
  • Three-Year Guardian Warranty
This Slope Laser can be set to cover DUAL Grade with adapter
  • Description
    The Pro Shot™ AS2 Magnum laser level is the class leader for delivering value in a precision slope laser. You can enter the grade with up to 25% with resolution down to .01%. That is fine enough to set specified slopes straight from an engineer's cut sheet on a sanitary sewer project. This servo self leveling laser won't let you down, with degrading accuracy as higher slopes are entered, like its competitors. It is also fully self leveling when slope is dialed-in.

    • Line up the laser, dial in your percent of grade.
    • No slope matching necessary.
    • Servo motor self-leveling for horizontal (level) and single grade for pads or slopes.
    • The Pro Shot AS2 Magnum Slope Laser is powered by 4 C Alkaline batteries or optional rechargeable batteries.
    • The Pro Shot AS2 Magnum model includes the S2 compound slope adapter for dual grade jobs.
    • 3 rotation speeds for machine control compatibility: 600, 900 and 1200rpm.
    • The Pro Shot AS2 Magnum works for the large grading, underground, and pipe laying, utility trenching operations, and basements.
    • Beam is visible to help with location at long distances.
    • Elevation Alert feature safeguards laser going out of level.
    • Made in the USA.
    • Benchmark Bob says: "Thousands of contractors rely on Pro Shot AS2 slope lasers, best for the buck laser level."
  • Specifications
    Laser receiver / detector
    Pro Shot R8
    Accuracy
    ± 10 arc sec (± 1/16" per 100') (± 1.5mm per 30m)
    Range with detector (diameter)
    3300' (1km)
    Slope capability
    0 to 25% single axis, .01% increments
    Self leveling type; range
    Servo motor; ± 4º
    Height alert
    Normally active, can be disabled
     Rotation coverage
    360º
    Laser beam type; rotation speed
    Visible 670nm; 600 - 900 - 1200rpm (selectable)
    Laser classification
    CDRH class IIIa, IEC class 3R
    Machine control compatible
    Yes, used with multiple speeds for precision
    Battery life
    90 hrs with 4 C-cells, 65 hrs with optional Ni-MH rechargeable battery
    Operating temperature
    -4º F to +140º F (-20º C to +60º C)
    Water and dust resistant
    IP56
    Warranty
    36 month Guardian
